Introduction:
BEC30050 is a bidirectional DC2DC converter, it can be used for connecting
the battery to a DC bus, the battery can discharge or been charged though the
same converter. It has high frequency transformer insulation, high efficiency,
high power density, high reliability advantage. The source side range is from
100 to 360VDC, 15kw Power, compliant with CE safety requirement, EMC
standard , EN61000-6-1 and EN61000-6-3 CLASS A, it is an innovative product for the energy storage application.
Unique function:
● Bidirectional converter
● Inside High frequency transformer insulation
● Smooth transition when power flow changing direction
Main feature:
● Constant current keeps the larger power in source side
● High efficiency higher than 97.5%
● Low standby power consumption, less than 10w
● Maximum 32 converters in parallel
● Plug & play
● Dual CAN interface
● Wide operation temperature range, -40℃–+70℃
APPLICATION:
● EV charger with Energy storage
● Smart Grid with DC bus and Energy storage
